Stainless steel flanged flexible joint

When searching for a pipeline connection solution that withstands vibration and thermal expansion, the SS400 steel flanged flexible joint combined with 304 stainless steel material is a suitable choice for many industrial systems. This product is designed to absorb vibration, minimize noise, and compensate for pipeline size misalignment during operation, helping the system operate more stably and durably over time.

Structure and Technical Specifications of the Stainless Steel Flanged Flexible Joint

The product is designed with an optimal structure to meet the stringent requirements of industrial piping systems. The main components include the flexible hose body and the outer braided layer.

1. Hose body and braid: Manufactured from high-quality 304 stainless steel material, offering good corrosion resistance in various common fluid environments.
2. Two-end connection: Utilizing sturdy flanges made from SS400 steel, making installation and bolt tightening to the pipeline system easy, fast, and leak-tight.
3. Diverse designs: The product comes in two design options, including a braided type for enhanced pressure resistance and a non-braided type depending on the specific requirements of each system.

Standard Dimensions and Application

To meet practical installation needs in factories, water supply and drainage systems, fire protection (PFIRE), or M&E systems, this product line is manufactured with a very wide size range.

Standard dimensions of flanged flexible joints start from 20A, 25A, 32A, 40A, 50A, 65A, 80A, 100A, 125A, 150A, 200A up to large sizes such as 400A and many other specifications. Thanks to this abundant size range, the product easily integrates into piping systems ranging from small to large scales, helping to minimize stress caused by vibrations from pumps or temperature changes on the system.

Advantages of Using Stainless Steel 304 Hose and Braided Flexible Joints

Applying 304 stainless steel material combined with SS400 steel flanges brings many practical benefits to users:

1. Effective vibration absorption capacity from pumps, air compressors, and other mechanical equipment, protecting welded joints and fixed pipe sections from the risk of cracking and fracturing.
2. 304 stainless steel material helps the hose body resist most common acids, alkalis, and chemicals at appropriate levels while withstanding stable working temperatures.
3. SS400 steel flanges have high rigidity, making them easy to weld and fabricate according to currently popular flange standards.

Notes on Selecting and Installing the Product

To ensure maximum lifespan and operating performance for the piping system, technicians need to note the following important points when purchasing and installing:

1. Accurately determine the nominal diameter (size) of the piping system, from 20A to 400A or equivalent specifications.
2. Choose the correct connection type (braided or non-braided) depending on the actual working pressure of the fluid flow.
3. Check the SS400 steel flange standards at both ends to ensure compatibility with existing valve or pipeline flanges at the construction site.
4. Install correctly according to technical standards, avoiding excessive twisting of the flexible joint or subjecting it to tension exceeding the design limit during flange bolt tightening.

Contact for Consultation and Ordering

CÔNG TY TNHH SX TM VÀ DỊCH VỤ CƠ KHÍ TẤN ĐẠT specializes in providing high-quality mechanical products, flexible hoses, and joints serving the industry. If you need detailed consultation on dimensions, designs, and quotation for the SS400 steel flanged flexible joint, please contact us directly:
