DN125 L=300mm 304 stainless steel expansion joint with PN16 carbon steel flange

When looking for thermal compensation and vibration damping solutions for industrial piping systems, the DN125 304 stainless steel pasty expansion joint with carbon steel PN16 flanged connection is one of the essential devices that help the system operate stably against temperature changes. The product is custom-fabricated to meet technical requirements according to samples, fully complying with current mechanical standards.

Detailed structure of the DN125 L=300mm pasty expansion joint

The device is composed of high-quality components, ensuring durability during use:

1. 304 stainless steel corrugated hose: Acts as the main body with good elasticity, made of stainless steel material to effectively resist corrosion in various common fluid environments.
2. 304 stainless steel inner sleeve: Enhances the structural strength of the internal flow, minimizing flow turbulence and material wear.
3. Carbon steel PN16 flange: Used for secure connection to the piping system, capable of withstanding working pressure according to the PN16 standard.
4. Guiding pasty: The product is equipped with 4 guiding pasties, which help accurately fix the expansion movement direction of the joint and limit misalignment.

Technical characteristics and thermal expansion compensation capacity

During operation, piping systems are regularly subjected to temperature effects, leading to expansion or contraction. With a length of L = 300mm and a flexible expansion range from -45mm to +10mm, this device effectively absorbs temperature variations, protecting welded joints and the entire system from overload stress.

The main material of the body is stainless steel and carbon steel, providing reliable durability. However, when choosing installation, operating engineers must pay attention to the material compatibility with the specific fluid and the actual working temperature of the system for optimal efficiency.

Practical applications of the DN125 304 stainless steel pasty expansion joint

The product is widely applied in industrial piping systems such as:

1. Water supply and drainage systems, factory wastewater treatment systems.
2. Steam, compressed air, and HVAC systems.
3. Technological production lines with frequent pipeline temperature fluctuations.

Contact to order genuine pasty expansion joints at Tan Dat

TAN DAT MECHANICAL PRODUCTION TRADING AND SERVICE CO., LTD specializes in supplying high-quality mechanical products, joints, and pipe fittings. If you need detailed consultation on the DN125 304 stainless steel pasty expansion joint with carbon steel PN16 flanged connection or other specifications, please contact us directly:
