DN250 unbraided guided expansion joint with inner sleeve
Detailed information about the unbraided stainless steel guided expansion joint with inner sleeve provided by Tan Dat. This equipment effectively compensates for thermal expansion in industrial piping systems.
- Certified stainless steel of the correct grade
- 100% pressure tested before shipment
- Made to your size and connection type
- Factory prices – good discounts for dealers and contractors
Price: Contact us for the best price
- Fast quotation
- Direct manufacturer
- Project partnership
- Nationwide delivery
Specifications
| Nominal diameter | 20A ÷ 300A |
|---|---|
| Standard connection | JIS, ANSI, DIN / SS400 / SUS304 |
| Connection material | Carbon steel, stainless steel |
| Applicable media | Hot steam, cold water, air, gas, and oil |
| Operating pressure | Max 10, 20, 30, … kgf/cm2 |
| Operating temperature | Max 350ºC – 500ºC |
| Expansion capacity | -45mm -> +10mm |
| Connection | JIS, ANSI, DIN/PS |
Description
The unbraided expansion joint with inner sleeve product is an effective engineering solution that helps compensate for thermal length changes in industrial piping systems. This equipment is specially designed to absorb axial movements and protect the piping systems from thermal stresses generated during operation.
Overview of unbraided expansion joints with inner sleeve and guide pasty
In high-temperature piping systems such as hot steam, air, gas, and oil, thermal expansion is an inevitable phenomenon. The use of compensation devices is essential to ensure the durability of the entire system. This product is designed without an external braided mesh, combined with a pasty and an inner sleeve to stabilize the flow and better guide the movement.
Technical characteristics and product specifications
The equipment is manufactured from high-quality materials, meeting the strict requirements of industrial plants. The nominal diameter of the product ranges from 20A to 200A, suitable for various pipe sizes. The maximum operating pressure resistance reaches 10, 20, or 30 kgf/cm2 depending on the design requirements of the system. In addition, the maximum operating temperature can reach from 350ºC to 500ºC, well suited for harsh working environments.
Application advantages in piping systems
Thanks to the unbraided design with guide pasty, the product helps minimize flow turbulence and protect the internal expansion element. The expansion capacity of the equipment ranges from -45mm to +10mm, allowing for the effective compensation of generated thermal fluctuations. The equipment is highly compatible with media such as hot steam, cold water, air, gas, and oil, helping to optimize operating performance and extend the service life of the piping system.
End connection standards and manufacturing materials
To ensure compatibility and easy installation, the product supports various diverse connection standards including JIS, ANSI, DIN, and PS. The connection manufacturing materials are diverse with carbon steel and stainless steel, helping engineers easily choose the right solution for the fluid environment and technical requirements of the project.
Contact for consultation and ordering
TAN DAT MECHANICAL TRADING AND SERVICE COMPANY LIMITED specializes in providing quality mechanical products and pipeline equipment. To receive a detailed quotation and technical consultation for the stainless steel unbraided expansion joint with inner sleeve and guide pasty, please contact:
- Tan Dat Flex
- Hotline: 0906 304 114
- Zalo: 0906304114
- Email: khopgiannoinox.vn@gmail.com
Frequently asked questions about compensators with inner sleeve
What is the nominal diameter of this expansion joint?
The product has a nominal diameter range from 20A to 200A.
What is the maximum operating temperature of the equipment?
The maximum operating temperature of the product reaches from 350ºC to 500ºC.
What types of media is this expansion joint used for?
The product is suitable for hot steam, cold water, air, gas, and oil.
What is the expansion capacity of the expansion joint with inner sleeve?
The expansion capacity of the equipment ranges from -45mm to +10mm.
